2.54 mm pitch 2a pogo pin electrical spring connector supplier in China. DIP type pogo pin with positioning pin on the bottom of barrel. Hard to shift after mounted on PCB Good performance on positioning. Pogo pin is a special connector the basic structure of a turning barrel, a cutting plunger and Compression spring. The barrel tube mouth edge, keep the plunger in the barrel, by the spring provide contact force the Electrical connections between plunger and the butt joint parts.
 |
Part No. | BE03922 | |
| Materials | Plunger | Brass 20u” Au over 50u” Ni | |
| Barrel | Brass 15u” Au over 50u” Ni | ||
| Spring | SUS 1u” Au | ||
| Bead | Ceramic bead | ||
| Mechanical | Contact force | 100g±20g at 0.8mm working stroke | |
| Full stroke | 0.8mm | ||
| Life test | 10,000 cycles | ||
| Electrical | Rated current and voltage | DC 20V; 5A | |
| Contact-resistance | 50milliohm Max | ||
Learn more about How to order special Pogo Pin connector, If you have special requirements please contact us
